Product description
Main Technical Specifications
| Item | Specification |
|---|---|
| PP Preheating Method | Vacuum-coated infrared lamps |
| Cross-Cutting Heating Power | 5 kW |
| Slitting Heating Power | 2 kW |
| Total Installed Power | 16 kW |
| Preheating Temperature | Below 100°C |
| Heating Power Adjustment | Adjustable via the control screen according to operating requirements |
| Preheating Time | 0.3–1.5 seconds, adjustable according to material specifications |
| Preheating Process | Completed during machine operation without affecting production speed |
| Compressed Air Requirement | Above 0.5 MPa |
| Cooling Water Flow | 2.5 m³/h |
| Chiller Power | 4.3 kW |
Product Advantages
- Advanced Feeding System
The independently developed feeding system improves loading efficiency and reduces labor requirements. - Cost-Effective Production
Standardized, large-scale manufacturing helps control production costs and provides competitive pricing. - Extensive Industry Experience
Years of industry experience ensure reliable machine design, manufacturing and technical support. - Excellent Cost Performance and Ready Stock
The machine offers excellent value, with units available from stock for shorter delivery times. - Advanced and Reliable Technology
The equipment delivers stable operation, consistent performance and high reliability.
