Product description
Main Technical Specifications
| Item | Specification |
|---|---|
| Machine Model Width | 1,300–1,600 mm |
| Maximum Material Width | 1,600 mm |
| Material Weight Range | 30–400 g/m² |
| Maximum Unwinding Diameter | Ø1,400 mm |
| Maximum Rewinding Diameter | Ø1,000 mm |
| Finished Roll Width | 50–1,600 mm |
| Rewinding Air Shaft | Two 3-inch air-expansion shafts |
| Number of Rewinding Shafts | 2 |
| Slitting Accuracy | ±0.3 mm |
| Mechanical Speed | 100–500 m/min |
| Total Power | Approximately 26 kW |
| Machine Dimensions | 4,500 × 3,900 × 1,950 mm |
| Machine Weight | Approximately 5,500 kg |
| Standard Machine Color | White |
| Web Guiding System | Photoelectric edge-position control system |
Applicable Materials
- Aluminum foil packaging materials
- Packaging paper
- PET film
- PVC film
- BOPP film
- Other plastic films
- Non-woven fabrics
Product Advantages
- Wide Material Compatibility
Suitable for large-scale slitting of aluminum foil, packaging paper, PET, PVC, BOPP and other films, as well as non-woven fabrics. - Cost-Effective Production
Standardized, large-scale manufacturing helps control production costs and provides competitive pricing. - Extensive Industry Experience
Years of industry experience support reliable machine design, manufacturing and technical service. - Excellent Value and Ready Stock
The machine offers excellent cost performance, with units available from stock for shorter delivery times. - Stable and Reliable Technology
Advanced technology ensures stable operation, accurate slitting and reliable long-term performance.
